10KW Automatic Bottle Labeling Machine Hot Glue Labeler 200mm Height

Manufacturer Price Automatic High Speed Linear OPP Hot Melt Glue Labeling Machine for Plastic Glass Bottle

The Roll-Fed labelling station is equipped with two IT independent reel stands, complete with film tension control device. During its unwinding, the film is controlled by a continuous, automatic correcting system of its vertical position [web tracker]. The film feeding roller is controlled by a servo-motor which adjusts the film feeding speed in accordance with the labels pitch (spot or other reference). The label is cut onto a drum provided with rotating blade which interferes with a static blade. The fine adjustment of the alignment of the two blades, necessary for a correct cutting and a long life of the blades, is simple and reliable. The transfer of the label from the cutting drum to the container is carried out by means of an aluminium vacuum drum.There is no slipping between the cut label and the vacuum drum: the machine functioning does not depend on the variation of the parameters related to the label material and to the upper finishing of the vacuum drum. The label process is therefore less critical. The Hot-Melt glue is spread on one edge of the label and on the overlap by means of a glue roller made of stainless steel, provided with a high precision and finely knurled cylindrical surface permitting a minimum consumption of glue. The labelling station position may be adjusted either vertically or horizontally, in order to allow the handling of containers of different diameters and the application of labels at different heights.

Flexibility
